Image Sensor:

5MP CMOS Image Sensor

Effective Pixels:

2592(H)*1944(V)

Shutter Time:

1/25(1/30) s to 1/50,000 s

Lens Mount:

M12

Adjustment Range:

Pan: 0° to 360°; Tilt: 0° to 75°; Rotate: 0° to 360°

Day& Night:

IR cut filter with auto switch

Video Frame Rate:

2592×1944@20fps

HD Video Output:

1 Analog HD output

Synchronization:

Internal/Power synchronization

D/N Mode:

Auto / Color / B/W

Auto White Balance:

Auto/MWB

BLC:

Support

AGC:

Support

Language:

English/Chinese

Operating Conditions:

-40 °C - 60 °C (-40 °F - 140 °F)
Humidity 90% or less (non-condensing)

Power Supply:

12 VDC±30%

Weather Proof:

IP67

IR Range:

Approx 10 to 20 meters

Communication :

Up the coax
Protocol: HIKVISION-C(Coaxitron)

Dimension:

91 mm × 82.6 mm × 68.3 mm (3.58" × 3.25" × 2.69")

Weight:

Approx. 350 g (0.77 lb)

Audio Input:

4-ch

Video Compression:

H.265+/H.265/H.264+/H.264

Analog and HD-TVI video input:

4-ch,BNC interface (1.0Vp-p, 75 Ω)connection

Supported camera types:

Support HDTVI input: 5MP,4MP,3MP,1080P/25Hz, 1080P/30Hz,720P/25Hz, 720P/30Hz, 720P/50Hz, 720P/60Hz,
Support AHD input: 1080P/25Hz, 1080P/30Hz, 720P/25Hz, 720P/30Hz
Support CVI input: 1080P/25Hz, 1080P/30Hz, 720P/25Hz, 720P/30Hz
Support CVBS input

Video Input Interface:

BNC (1.0 Vp-p, 75Ω)

Audio Compression:

G.711u

Audio Input Interface:

4-ch, RCA (2.0 Vp-p, 1 KΩ)

Two-way Audio:

1-ch, RCA (2.0 Vp-p, 1 KΩ), (using the 1st channel of audio input)

CVBS Output:

1-ch,BNC(1.0Vp-p,75Ω),resolution:PAL:704x576,NTSC:704x480

HDMI/VGA Output:

VGA: 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
HDMI: 1ch, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz

Recording resolution:

5 MP/4 MP/3 MP/1080p/720p/WD1/4CIF/VGA/CIF

Frame Rate:

Main stream: 5 MP@12fps/4 MP@15fps/3 MP@18fps1080p/720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N)
Sub-stream: WD1/4CIF/CIF@25fps (P)/30fps (N)

Video Bit Rate:

32 Kbps-10 Mbps

Stream Type:

Video/Video&Audio

Two-way Audio:

1-ch, RCA (2.0 Vp-p, 1 kΩ) (using the audio input)

Audio Output:

1-ch RCA(Linear, 1kΩ)

Audio Bit Rate:

64kbps

Dual Stream:

Support

Playback Resolution:

5MP/4MP/3MP/1080p/720p/VGA/WD1/4CIF/CIF/QVGA/QCIF

Synchronous Playback:

8-ch

Remote connections:

128

Network protocols:

TCP/IP, PPPoE, DHCP, Hikconnect Cloud P2P,DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS,ONVIF

Interface Type:

1 SATA Interface

Capacity:

Up to 8 TB capacity for each disk

Network Interface:

1; 10M / 100M / 1000M self-adaptive Ethernet interface

USB Interface:

1 USB 2.0 Interface & 1 USB 3.0 Interface

Serial Interface:

1; standard RS-485 serial interface, half-duplex

Alarm Input:

4-ch

Alarm Output:

4-ch

Power Supply:

12 VDC

Consumption:

≤ 20W(without hard disks)

Working Temperature:

-10 ºC to +55 ºC (14 ºF to 131 ºF)

Working Humidity:

10% to 90%

Dimensions:

315 × 242 × 45 mm (12.4 × 9.5 × 1.8 inch)

Weight:

≤ 2 kg (4.4 lb)
