| Camera | |
|---|---|
| Image Sensor: | 1/3" Progressive Scan CMOS |
| Min. Illumination: | 0.07Lux @ (F1.2, AGC ON) ,0 Lux with IR 0.19 Lux @ (F2.0, AGC ON) ,0 Lux with IR |
| Shutter time: | 1/3 s to 1/100,000 s |
| Lens: | 4mm@ F2.0 (2.8mm, 6mm optional), Angle of view: 98.5°(2.8mm), 79°(4mm) , 49°(6mm) |
| Lens Mount: | M12 |
| Adjustment Range: | Pan:0° - 355°, Tilt: 0° - 75°, Rotation: 0-355° |
| Day& Night: | IR cut filter with auto switch |
| Wide Dynamic Range: | 120 dB |
| Digital noise reduction: | 3D DNR |
| Compression Standard | |
| Video Compression: | H.264/MJPEG/H.264+ |
| H.264 code profile: | Main profile |
| Video bit rate: | 32Kbps~16Mbps |
| Audio Compression: | -S: G.711/G.722.1/G.726/MP2L2 |
| Audio bit rate: | 64Kbps(G.711) /16Kbps(G.722.1)/16Kbps(G.726) /32-128Kbps(MP2L2) |
| Dual Stream: | Yes |
| Image | |
| Max. Image Resolution: | 2688 × 1520 |
| Frame Rate: | 50Hz: 20fps (2688×1520), 25fps(1920×1080), 25fps(1280×720) 60Hz: 20fps (2688×1520), 30fps (1920×1080), 30fps(1280×720) |
| Image Settings: | Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser |
| BLC: | Yes, zone configurable |
| ROI: | Support |
| Network | |
| Network Storage: | NAS (Support NFS,SMB/CIFS), ANR |
| Protocols: | TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP, PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour |
| Alarm Trigger: | Line Crossing, Intrusion Detection, Motion detection, Dynamic analysis, Tampering alarm, Network disconnect , IP address conflict, Storage exception |
| System Compatibility: | ONVIF, PSIA, CGI, ISAPI |
| Interface | |
| Audio: | 1-ch 3.5 mm audio in (Mic in/Line in)/out interface (-S model) |
| Communication Interface: | 1 RJ45 10M / 100M Ethernet interface |
| Alarm: | -S: 1 alarm I/O |
| On-board storage: | Built-in Micro SD/SDHC/SDXC slot, up to 128 GB |
| Wi-Fi Specification (-W) | |
| Wireless Standards: | IEEE802.11b, 802.11g, 802.11n |
| Frequency Range: | 2.4 GHz ~ 2.4835 GHz |
| Channel Bandwidth: | 20/40MHz Support |
| Modulation Mode: | 802.11b: CCK, QPSK, BPSK 802.11g/n: OFDM |
| Security: | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS |
| Transmission Rate: | 11b: 11Mbps 11g: 54Mbps 11n: up to 150Mbps |
| Wireless Range: | 50m(depend on environment) |
| General | |
| Operating Conditions: | -30 °C ~ 60 °C (-22 °F ~ 140 °F) Humidity 95% or less (non-condensing) |
| Power Supply: | 12 VDC ± 25%, PoE (802.3af Class3) |
| Power Consumption: | Max. 5 W |
| Impact Protection: | IK10 |
| IR Range: | Up to 30m |
| Dimensions: | Φ111 × 82 (4.4” × 3.2”) |
| Weight: | 500g (1.1 lbs) |
| NOTE?: | "-W" series support Wi-Fi (802.11b/g/n) and the modules with Wi-Fi function don’t support the 802.1X protocol. |
