Image Sensor:

5MP CMOS Image Sensor

Effective Pixels:

2592(H)*1944(V)

Shutter Time:

1/25(1/30) s to 1/50,000 s

Lens Mount:

M12

Adjustment Range:

Pan: 0° to 360°; Tilt: 0° to 75°; Rotate: 0° to 360°

Day& Night:

IR cut filter with auto switch

Video Frame Rate:

2592×1944@20fps

HD Video Output:

1 Analog HD output

Synchronization:

Internal/Power synchronization

D/N Mode:

Auto / Color / B/W

Auto White Balance:

Auto/MWB

BLC:

Support

AGC:

Support

Language:

English/Chinese

Operating Conditions:

-40 °C - 60 °C (-40 °F - 140 °F)
Humidity 90% or less (non-condensing)

Power Supply:

12 VDC±30%

Weather Proof:

IP67

IR Range:

Approx 10 to 20 meters

Communication :

Up the coax
Protocol: HIKVISION-C(Coaxitron)

Dimension:

91 mm × 82.6 mm × 68.3 mm (3.58" × 3.25" × 2.69")

Weight:

Approx. 350 g (0.77 lb)
