Categorie: dvr
Audio Input: |
8-ch |
Video Compression: |
H.265+/H.265/H.264+/H.264 |
Analog and HD-TVI video input: |
8-ch,BNC interface (1.0Vp-p, 75 Ω)connection |
Supported camera types: |
Support HDTVI input: 5MP,4MP,3MP,1080P/25Hz, 1080P/30Hz,720P/25Hz, 720P/30Hz, 720P/50Hz, 720P/60Hz, |
Video Input Interface: |
BNC (1.0 Vp-p, 75Ω) |
Audio Compression: |
G.711u |
Audio Input Interface: |
4-ch, RCA (2.0 Vp-p, 1 KΩ) |
Two-way Audio: |
1-ch, RCA (2.0 Vp-p, 1 KΩ), (using the 1st channel of audio input) |
CVBS Output: |
1-ch,BNC(1.0Vp-p,75Ω),resolution:PAL:704x576,NTSC:704x480 |
HDMI/VGA Output: |
VGA: 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
Recording resolution: |
5 MP/4 MP/3 MP/1080p/720p/WD1/4CIF/VGA/CIF |
Frame Rate: |
Main stream: 5 MP@12fps/4 MP@15fps/3 MP@18fps1080p/720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N) |
Video Bit Rate: |
32 Kbps-10 Mbps |
Stream Type: |
Video/Video&Audio |
Two-way Audio: |
1-ch, RCA (2.0 Vp-p, 1 kΩ) (using the audio input) |
Audio Output: |
1-ch RCA(Linear, 1kΩ) |
Audio Bit Rate: |
64kbps |
Dual Stream: |
Support |
Playback Resolution: |
5MP/4MP/3MP/1080p/720p/VGA/WD1/4CIF/CIF/QVGA/QCIF |
Synchronous Playback: |
8-ch |
Remote connections: |
128 |
Network protocols: |
TCP/IP, PPPoE, DHCP, Hikconnect Cloud P2P,DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS,ONVIF |
Interface Type: |
1 SATA Interface |
Capacity: |
Up to 8 TB capacity for each disk |
Network Interface: |
1; 10M / 100M / 1000M self-adaptive Ethernet interface |
USB Interface: |
1 USB 2.0 Interface & 1 USB 3.0 Interface |
Serial Interface: |
1; standard RS-485 serial interface, half-duplex |
Alarm Input: |
8-ch |
Alarm Output: |
4-ch |
Power Supply: |
12 VDC |
Consumption: |
≤ 20W(without hard disks) |
Working Temperature: |
-10 ºC to +55 ºC (14 ºF to 131 ºF) |
Working Humidity: |
10% to 90% |
Dimensions: |
315 × 242 × 45 mm (12.4 × 9.5 × 1.8 inch) |
Weight: |
≤ 2 kg (4.4 lb) |
